E-ACE 4G LTE DashCam With Built-in SIM Card Remote Live View 24/7 Parking Monitor GPS Track 2-Way Audio For Fleet Safety Monitor
E-ACE 4G LTE DashCam With Built-in SIM Card Remote Live View 24/7 Parking Monitor GPS Track 2-Way Audio For Fleet Safety Monitoring
Special Note: ★Prohibit the use of USBdata cable to connect the machine to boot, it will lead to insufficient voltage on the machine motherboard to repeat the boot or can not start, easy to make the machine damaged! ★Since electronic products have strict voltage requirements, please use our standard car charger for power supply. If we do not configure the charger, the machine may not work normally. Please use our products correctly to avoid damage to the machine caused by improper operation. 3.Note: Since its internal battery is a small capacity, it will automatically shut down without external power. You need to always connect to external power when using the cam.
★The driving recorder has high requirements for memory cards. Please use a professional driving recorder card with a CLASS10 or higher memory card, otherwise it may cause issues such as inability to record videos and video lag.
★The following are the frequency bands supported by the device, please make sure your SIM card supports the following frequency bands, otherwise it cannot support the use.
LTE Band:
1.Europe/Asia/Oceania/Africa/South America
FDD:B1/B3/B5/B8
2.Europe/Asia/Oceania/Africa/South America
TDD:B34/B38/B39/B40/B41)
SIM card country table
Product Description
●Dashcam: 4g Lte Dashcam Single Channel
●Type: Video Recorder, LSingle LENS, DASH CAM
●Angle: 170°
●Function: NIGHT VISION, WDR, FULL COLOR, park MODE, Loop recording, APP Control, Voice Interaction, Emergency Accident Lock, Bilt In Gps, Cloud Storage, Lte Cloud Mointoring
●Screen Type: NO Screen (Can be Seen Through App)
●Lens Amount: Single Lens
●Number of cameras: 1
●Voltage:12V±5%@(Type-C)
●Working Temperature Range: -30℃ - 80℃
●Warranty: 12 Months
●Place of Origin: China
●Front camera: HD 1080P @25 Fps
●Rear camera: Not Supported
●Compression mode: MJPEG
●Time-lapse video: Support ACC
●Memory Card: Up To 128GB
●Battery: 5mAh
Min Features
4G Dash Cam
Ultra wide 170 degree shooting angle,reducing blind spots
4G Chip Advantages
Use TF card for recording (auto-loop when full, no manual delete). Supports remote video playback & download, convenient.a
App Timeline Playback
Click timeline to view any moment easily
Secure Cloud Storage
Auto-upload accident photos/videos to cloud, avoiding data loss from TF card issues.
One Click Car Location
Quickly locate car & plan route. Works in parking lots/city, saves search time.
Trajectory Playback
View driving trajectory, speed, parking via app. Aids route viewing & driving analysis.
Electronic Fence
Set fence in app, get notified on vehicle entry/exit. Manages parking easily.
Night Vision Dash Cam
Clearly captures license plates at night (even in dim light), with sharp day & night imaging.
24 Hours Parking Mode
G-Sensor Collision Recording: Sleeps, records on collision (low voltage protection).
Intelligent Mode:Runs 24h, sleeps at low voltage, records on collision (low voltage protection).
Quick Start Recording on Collision
Built-in G-Sensor triggers instant recording/photos during collisions, providing evidence for accidents, fraud, etc.
Low Power Parking Monitoring
Auto-switches to low power (≤11.8V, no battery/memory harm), 24H non-loop monitoring. G-Sensor wakes cam on motion/impact, uploads video to cloud for anytime access.
Installation rendering
Buck line
You will need to find two fuse slots to be used in this step.
1.A fuse Slot that provides constant power (RED wire will go here)
2.A fuse Slot that only provides power when you turn your key to ACC position (YELLOW wire will go here)
3.Connect the BLACK Wire to the Grounding Screw or Bolt.
Six sided diagram
Product dimension diagram
Packaging listing
