20x4 2004 LCD Display Module with IIC/I2C Serial Interface Adapter IIC I2C TWI Serial 2004 20x4 LCD Module Shield for Arduino R3

IIC 2004 IIC I2C TWI Serial 2004 20x4 LCD Module Shield Compatible with Arduino R3 MEGA To Display Characters, letters and Numbers

Overviews:

With the LCD shield, you can display whatever you want by programming compatible with Arduino board or Raspberry Pi.

Therefore, this is a perfect choice to make your project more interesting and vivid!

Features:

IIC 2004 IIC I2C TWI Serial 2004 20x4 LCD Module Shield characters of 4 rows with 20 characters in each.

Working voltage: 5V DC; Dimension: 60×99x22 mm.

IIC/I2C interface; only takes two I/O ports.

I2C Address: 0x27 or 0x3F.Compatible with Arduino R3/2560 board.

User Guide: //a.d4t.cn/MQ9bJw

Application Used to display Characters, letters and Numbers.

Specification:

Display: 4 lines x 20 characters

Backlight: Blue with white character color

Pin Definition: VCC/ GND/SDL and SCA

Contrast Adjust: Potentiometer

Backlight Adjust: Jumper

Default Address: 0x27, 0x3F

Working Voltage: 5V

Package:

1 x blue 20x4 2004 lcd display+ I2C serial interface
